Article number

23000000

23000500

Permissible mains voltage

220–240 V

220–240 V

Permissible mains frequency

50/60 Hz

50/60 Hz

Power consumption

1900 W

1900 W

Mains input fuse

12 A(T)

12 A(T)

Temperature range

0–1100 °C
30–2010 °F

0–1100 °C
30–2010 °F

Programmable heating rate

0–9 °C/min
0–17 °F/min

0–9 °C/min
0–17 °F/min

Max. heat-up rate in 1 hour

900 °C
1652 °F

900 °C
1652 °F

Number of programmable stage programs

99

99

Number of speed programs

1

1

Volume (Muffle)

3,45 l
0.91 gal

3,45 l
0.91 gal

Type temperature sensor

PtRh-Pt

PtRh-Pt

Dimensions (W x H x D) (incl. one handle and flue)

430 x 500 x 440 mm
16,9 x 19,7 x 19,3"

430 x 500 x 440 mm
16,9 x 19,7 x 19,3"

Dimensions (W x H x D) (incl. one handle and catalyst converter)

430 x 610 x 550 mm
16,9 x 24,0 x 21,7"

430 x 610 x 550 mm
16,9 x 24,0 x 21,7"

Dimensions (W x H x D) (muffle)

160 x 120 x 180 mm
6,3 x 4,7 x 7,1"

160 x 120 x 180 mm
6,3 x 4,7 x 7,1"

Weight (incl. flue)

~30 kg
~66.1 lbs

Weight (incl. catalyst converter)

~34,8 kg
~76.7 lbs
